Deep learning at scale: lesson from experiments from Perlmutter

import torch.nn.functional as F
import torch
import torch.nn as nn
from functools import partial
from networks.helpers import DropPath, trunc_normal_

# mp stuff
from utils import comm
from distributed.layers import (
    DistributedMatmul,
    DistributedMLP,
    DistributedAttention,
    DistributedLayerNorm,
)
from distributed.helpers import compute_split_shapes
from distributed.mappings import scatter_to_parallel_region, gather_from_parallel_region


class MLP(nn.Module):
    def __init__(
        self,
        in_features,
        hidden_features=None,
        out_features=None,
        act_layer=nn.GELU,
        drop=0.0,
    ):
        super().__init__()
        out_features = out_features or in_features
        hidden_features = hidden_features or in_features
        self.fc1 = nn.Linear(in_features, hidden_features)
        self.act = act_layer()
        self.fc2 = nn.Linear(hidden_features, out_features)
        self.drop = nn.Dropout(drop)

    def forward(self, x):
        x = self.fc1(x)
        x = self.act(x)
        x = self.drop(x)
        x = self.fc2(x)
        x = self.drop(x)
        return x


class Attention(nn.Module):
    def __init__(self, dim, num_heads=8, qkv_bias=False, attn_drop=0.0, proj_drop=0.0):
        super().__init__()
        assert dim % num_heads == 0, "dim should be divisible by num_heads"
        self.num_heads = num_heads
        self.head_dim = dim // num_heads
        self.scale = self.head_dim**-0.5
        self.fused_attn = True

        #        self.qkv = nn.Linear(dim, dim * 3, bias=qkv_bias)
        self.q = nn.Linear(dim, dim, bias=qkv_bias)
        self.k = nn.Linear(dim, dim, bias=qkv_bias)
        self.v = nn.Linear(dim, dim, bias=qkv_bias)
        self.attn_drop = nn.Dropout(attn_drop)
        self.proj = nn.Linear(dim, dim)
        self.proj_drop = nn.Dropout(proj_drop)

    def forward(self, x):
        B, N, C = x.shape

        q = self.q(x).reshape(B, N, self.num_heads, self.head_dim).permute(0, 2, 1, 3)
        k = self.k(x).reshape(B, N, self.num_heads, self.head_dim).permute(0, 2, 1, 3)
        v = self.v(x).reshape(B, N, self.num_heads, self.head_dim).permute(0, 2, 1, 3)

        if self.fused_attn:
            x = F.scaled_dot_product_attention(
                q,
                k,
                v,
                dropout_p=self.attn_drop.p,
            )
        else:
            q = q * self.scale
            attn = q @ k.transpose(-2, -1)
            attn = attn.softmax(dim=-1)
            attn = self.attn_drop(attn)
            x = attn @ v

        x = x.transpose(1, 2).reshape(B, N, C)
        x = self.proj(x)
        x = self.proj_drop(x)
        return x


class Block(nn.Module):
    def __init__(
        self,
        dim,
        num_heads,
        mlp_ratio=4.0,
        qkv_bias=False,
        drop=0.0,
        attn_drop=0.0,
        drop_path=0.0,
        act_layer=nn.GELU,
        norm_layer=nn.LayerNorm,
        cp_shapes=None,
    ):
        super().__init__()

        mlp_hidden_dim = int(dim * mlp_ratio)

        self.drop_path = DropPath(drop_path) if drop_path > 0.0 else nn.Identity()
        if (comm.get_size("tp-cp")) > 1:
            # model parallelism is on, distribute the layers
            # tp: tensor parallel shards the weights
            # cp: context parallel shards the sequence
            self.norm1 = DistributedLayerNorm(dim, comm_tp_name="tp", comm_cp_name="cp")
            self.norm2 = DistributedLayerNorm(dim, comm_tp_name="tp", comm_cp_name="cp")
            self.attn = DistributedAttention(
                dim,
                num_heads=num_heads,
                qkv_bias=qkv_bias,
                attn_drop=attn_drop,
                proj_drop=drop,
                comm_tp_name="tp",
                comm_cp_name="cp",
                cp_shapes=cp_shapes,
            )
            self.mlp = DistributedMLP(
                in_features=dim,
                hidden_features=mlp_hidden_dim,
                act_layer=act_layer,
                drop=drop,
                comm_tp_name="tp",
                comm_cp_name="cp",
            )
        else:
            self.norm1 = norm_layer(dim)
            self.norm2 = norm_layer(dim)
            self.attn = Attention(
                dim,
                num_heads=num_heads,
                qkv_bias=qkv_bias,
                attn_drop=attn_drop,
                proj_drop=drop,
            )
            self.mlp = MLP(
                in_features=dim,
                hidden_features=mlp_hidden_dim,
                act_layer=act_layer,
                drop=drop,
            )

    def forward(self, x):
        y = self.attn(self.norm1(x))
        x = x + self.drop_path(y)
        x = x + self.drop_path(self.mlp(self.norm2(x)))
        return x


class PatchEmbed(nn.Module):
    """Image to Patch Embedding"""

    def __init__(self, img_size=[224, 224], patch_size=16, in_chans=3, embed_dim=768):
        super().__init__()
        # grid of patches
        self.h = img_size[0] // patch_size
        self.w = img_size[1] // patch_size
        num_patches = self.h * self.w
        self.img_size = img_size
        self.patch_size = patch_size
        self.num_patches = num_patches

        self.proj = nn.Conv2d(
            in_chans, embed_dim, kernel_size=patch_size, stride=patch_size
        )

    def forward(self, x):
        B, C, H, W = x.shape
        x = self.proj(x).flatten(2).transpose(1, 2)
        return x


class VisionTransformer(nn.Module):
    """
    Vision Transformer Architecture — Structure Diagram (Left-to-Right, Detailed)

    +-----------------+   +-----------------+   +-------------------------------+   +-----------------+   +-----------------+
    |   Input Image   |-->|   PatchEmbed    |-->| + Positional Embedding        |-->|    Dropout      |-->|     Scatter     |
    |   (B, C, H, W)  |   | Conv2d splits   |   | (learned, per token)          |   |   (pos_drop)    |   | to context      |
    |                 |   | into patches    |   |                               |   |                 |   | parallel        |
    +-----------------+   +-----------------+   +-------------------------------+   +-----------------+   +-------+---------+
                                                                                                                  |
                                                                                                                  v
----------------------------------------------- Transformer Encoder Blocks ---------------------------------------+-------------

                              Repeats "depth" times: (for i = 1 to depth)
+--------------+   +------------+   +--------------+   +------------+   +-------------+   +------------+   +-------------+
|    Input     |-->|   Norm1    |-->| Multi-Head   |-->|  DropPath  |-->|  Residual   |-->|   Norm2    |-->|    MLP      |
|  (B, N, D)   |   |(Layer/Dist)|   |  Attention   |   |(stoch.     |   | Connection  |   |            |   | (2 layers,  |
|              |   |            |   | (LN -> MHSA  |   | depth,     |   |   (+Input)  |   |            |   |  GELU,      |
|              |   |            |   |   QKV-Proj)  |   | optional)  |   |             |   |            |   |  Dropout)   |
+--------------+   +------------+   +--------------+   +------------+   +------+------+   +------------+   +------|------+
                                                                               ^                                  |
                                                                               |                                  v
                                                                               |                   +--------------+------+
                                                                               |------------------>|         DropPath    |
                                                                                                   +---------------------+

--------------+------------------------------------------------------------------------------------------------------------------
              |
              V
+-------------+-------------+   +------------------------------+   +-------------------------------+   +------------------------------+
|   LayerNorm /             |-->|    Gather from context       |-->|  Head: Linear projection      |-->|   Reshape & Rearrangement    |
| DistributedLayerNorm      |   |    parallel (if needed)      |   |  to patch×patch×channels      |   | (to output image shape)      |
+---------------------------+   +------------------------------+   +-------------------------------+   +------------------------------+

    Key Properties:
      - patch_embed: Converts image to sequence of patch tokens
      - pos_embed: Learnable position embeddings per token
      - blocks: N repeated Transformer blocks with LayerNorm, MHSA, MLP, DropPath and residual
      - norm: Final normalization; distributed option if needed
      - head: Linear projection from embedding space to reconstructed output
      - All computation left-to-right (data flow shown above)

    Notation:
      B = batch size, C = in channels, H,W = input dims, N = num patches, D = embed_dim

    """
    def __init__(
        self,
        img_size=[224, 224],
        patch_size=16,
        in_chans=3,
        out_chans=3,
        embed_dim=768,
        depth=12,
        num_heads=12,
        mlp_ratio=4.0,
        qkv_bias=False,
        drop_rate=0.0,
        attn_drop_rate=0.0,
        drop_path_rate=0.0,
        norm_layer=nn.LayerNorm,
        **kwargs
    ):
        super().__init__()
        self.num_features = self.embed_dim = embed_dim
        self.patch_size = patch_size
        self.img_size = img_size
        self.out_ch = out_chans
        self.drop_rate = drop_rate

        # ─── Patch Embedding ───────────────────────────────────────────────────────────
        self.patch_embed = PatchEmbed(
            img_size=img_size,
            patch_size=patch_size,
            in_chans=in_chans,
            embed_dim=self.embed_dim,
        )
        num_patches = self.patch_embed.num_patches

        # ─── Parallel Shapes for Sequence/Context ──────────────────────────────────────
        self.cp_shapes = compute_split_shapes(num_patches, comm.get_size("cp"))

        # ─── Learnable Positional Embedding ────────────────────────────────────────────
        self.pos_embed = nn.Parameter(torch.zeros(1, num_patches, self.embed_dim))
        self.pos_drop = nn.Dropout(p=drop_rate)

        # ─── Stochastic Depth/DropPath Scheduling ──────────────────────────────────────
        dpr = [
            x.item() for x in torch.linspace(0, drop_path_rate, depth)
        ]

        # ─── Stacked Transformer Blocks ────────────────────────────────────────────────
        self.blocks = nn.ModuleList(
            [
                Block(
                    dim=embed_dim,
                    num_heads=num_heads,
                    mlp_ratio=mlp_ratio,
                    qkv_bias=qkv_bias,
                    drop=drop_rate,
                    attn_drop=attn_drop_rate,
                    drop_path=dpr[i],
                    norm_layer=norm_layer,
                    cp_shapes=self.cp_shapes,
                )
                for i in range(depth)
            ]
        )

        # ─── Final LayerNorm (possibly distributed) ────────────────────────────────────
        if (comm.get_size("tp-cp")) > 1:
            self.norm = DistributedLayerNorm(embed_dim, comm_tp_name="tp", comm_cp_name="cp")
        else:
            self.norm = norm_layer(embed_dim)

        # ─── Head: Linear map to patch × patch × channel output ────────────────────────
        self.out_size = self.out_ch * self.patch_size * self.patch_size
        self.head = nn.Linear(embed_dim, self.out_size, bias=False)

        # ─── Initialization ────────────────────────────────────────────────────────────
        trunc_normal_(self.pos_embed, std=0.02)
        self.apply(self._init_weights)

    def _init_weights(self, m):
        if isinstance(m, nn.Linear):
            trunc_normal_(m.weight, std=0.02)
            if isinstance(m, nn.Linear) and m.bias is not None:
                nn.init.constant_(m.bias, 0)
        elif isinstance(m, nn.LayerNorm):
            nn.init.constant_(m.bias, 0)
            nn.init.constant_(m.weight, 1.0)

    def prepare_tokens(self, x):
        B, nc, w, h = x.shape
        x = self.patch_embed(x)  # patch linear embedding
        # add positional encoding to each token
        x = x + self.pos_embed
        return self.pos_drop(x)

    def forward_head(self, x):
        B, _, _ = x.shape  # B x N x embed_dim
        x = x.reshape(B, self.patch_embed.h, self.patch_embed.w, self.embed_dim)
        B, h, w, _ = x.shape

        # apply head
        x = self.head(x)
        x = x.reshape(shape=(B, h, w, self.patch_size, self.patch_size, self.out_ch))
        x = torch.einsum("nhwpqc->nchpwq", x)
        x = x.reshape(shape=(B, self.out_ch, self.img_size[0], self.img_size[1]))

        return x

    def forward(self, x):
        x = self.prepare_tokens(x)

        # split sequence if cp is on (shape of x is (batch, seq, embed))
        x = scatter_to_parallel_region(x, dim=1, comm_name="cp")

        # if cp is on, each block operates on a sequence shard
        for blk in self.blocks:
            x = blk(x)
        x = self.norm(x)

        # gather sequence if cp is on
        x = gather_from_parallel_region(x, dim=1, shapes=self.cp_shapes, comm_name="cp")

        x = self.forward_head(x)
        return x


def ViT(params, **kwargs):
    model = VisionTransformer(
        img_size=tuple(params.img_size),
        in_chans=params.n_in_channels,
        out_chans=params.n_out_channels,
        patch_size=params.patch_size,
        embed_dim=params.embed_dim,
        depth=params.depth,
        num_heads=params.num_heads,
        mlp_ratio=4,
        qkv_bias=True,
        norm_layer=partial(nn.LayerNorm, eps=1e-6),
        drop_path_rate=float(params.dropout),
        drop_rate=float(params.dropout),
        attn_drop_rate=float(params.dropout),
        **kwargs
    )
    return model

# -----------------------------------------------------------------------------
# How DALI Interacts with CUDA for Accelerated Data Loading
# -----------------------------------------------------------------------------
#
# The DALI pipeline is tightly integrated with CUDA. Its workers and GPU operators move data
# efficiently from storage to device, avoiding Python and host memory bottlenecks.
#
#                  +---------------------+   (1) read/augment   +-----------------+
# Data/FileSystem  | DALI CPU Workers    |--------------------->|   CPU Buffer    |
# (images, HDF5,   +---------------------+      (NumPy,        +-----------------+
#  .npy, etc.)                                    Pillow...)                 |
#          |                                                        (2) memcpy (optional)
#          |                                                                 |
#          |        +--------------+  (3) DALI GPU ops  +---------------------+
#          +------->| DALI Pipeline|------------------->|   CUDA Device Mem   |
#                   +--------------+ (Crop, Normalize,  +---------------------+
#                                     Augment, etc)               |
#                                                            (4) tensor returned to PyTorch on GPU, with no H2D copy needed.
#                                                                 |
#         [PyTorch training loop, tensor already in cuda:0, ready for GPU kernel]
#
#  - DALI operators marked as "device='gpu'" run as CUDA kernels and operate on device memory.
#  - No host-to-device PCIe transfers are needed after data is loaded into GPU memory.
#  - The pipeline uses internal CUDA streams and events for asynchronicity:
#         - Different sets of CUDA streams can be used for each worker/pipeline.
#         - DALI synchronizes only when the output tensor is returned to PyTorch.
#  - This approach is analogous to the CUDA buffer/execution region (see /distributed-gpu).
#
#      CPU (Data Workers)                  CUDA Device (GPU)           PyTorch Training Loop
#  +---------------------+             +----------------------+      +-----------------------+
#  | Disk/Net IO         |--read-----> | DALI pipeline ops    | ---> |   model(input.cuda()) |
#  | Decoding, Sharding  |             | (normalize, augment) |      +-----------------------+
#  | Preprocessing (CPU) |             +----------------------+        │
#  +---------------------+                    │                        │ Backprop
#                |                            └------------------------┘
#        sharding logic ensures
#        each GPU/process gets
#        the correct portion of data
#
#  See: Memory regions, CUDA device buffer layout, and device-kernel launches (cf. the
#  diagrams and commentary in /distributed-gpu).

class DaliDataLoader(object):
    def get_pipeline(self):
        pipeline = Pipeline(
            batch_size=self.batch_size,
            num_threads=2,
            device_id=self.device_index,
            py_num_workers=self.num_data_workers,
            py_start_method="spawn",
            seed=self.global_seed,
        )

        with pipeline:  # get input and target from external source
            inp, tar = fn.external_source(
                source=esh.ERA5ES(
                    self.location,
                    self.train,
                    self.batch_size,
                    self.dt,
                    self.img_size,
                    self.n_in_channels,
                    self.n_out_channels,
                    self.num_shards,
                    self.shard_id,
                    self.limit_nsamples,
                    enable_logging=False,
                    seed=self.global_seed,
                ),
                num_outputs=2,
                layout=["CHW", "CHW"],
                batch=False,
                no_copy=True,
                parallel=True,
            )

            # upload directly to GPU (DALI op executes as CUDA kernel)
            inp = inp.gpu()
            tar = tar.gpu()

            if self.normalize:
                inp = fn.normalize(
                    inp,
                    device="gpu",
                    axis_names="HW",
                    batch=False,
                    mean=self.in_bias,
                    stddev=self.in_scale,
                )

                tar = fn.normalize(
                    tar,
                    device="gpu",
                    axis_names="HW",
                    batch=False,
                    mean=self.out_bias,
                    stddev=self.out_scale,
                )

            pipeline.set_outputs(inp, tar)
        return pipeline

    def __init__(self, params, location, train, seed=333):
        # set up seeds
        self.global_seed = seed  # same seed across all ranks
        model_id = comm.get_world_rank() // comm.get_size("tp-cp-pp")
        self.model_seed = self.global_seed + model_id  # model-wise seed
        self.local_seed = self.global_seed + comm.get_world_rank()  # unique per-rank

        self.num_data_workers = params.num_data_workers
        self.device_index = torch.cuda.current_device()
        self.batch_size = int(params.local_batch_size)

        self.location = location
        self.train = train
        self.dt = params.dt
        self.n_in_channels = params.n_in_channels
        self.n_out_channels = params.n_out_channels
        self.img_size = params.img_size
        self.limit_nsamples = (
            params.limit_nsamples if train else params.limit_nsamples_val
        )

        # load normalization stats
        self.normalize = True
        means = np.load(params.global_means_path)[0][: self.n_in_channels]
        stds = np.load(params.global_stds_path)[0][: self.n_in_channels]
        self.in_bias = means
        self.in_scale = stds
        means = np.load(params.global_means_path)[0][: self.n_out_channels]
        stds = np.load(params.global_stds_path)[0][: self.n_out_channels]
        self.out_bias = means
        self.out_scale = stds

        # set sharding for distributed, or local single process
        if dist.is_initialized():
            self.num_shards = params.data_num_shards
            self.shard_id = params.data_shard_id
        else:
            self.num_shards = 1
            self.shard_id = 0

        # compute number of batches for __len__
        extsource = esh.ERA5ES(
            self.location,
            self.train,
            self.batch_size,
            self.dt,
            self.img_size,
            self.n_in_channels,
            self.n_out_channels,
            self.num_shards,
            self.shard_id,
            self.limit_nsamples,
            seed=self.global_seed,
        )
        self.num_batches = extsource.num_steps_per_epoch
        del extsource

        # create DALI pipeline & launch py workers
        self.pipeline = self.get_pipeline()
        self.pipeline.start_py_workers()
        self.pipeline.build()

        # Create iterator over GPU-preprocessed batches
        self.iterator = DALIGenericIterator(
            [self.pipeline],
            ["inp", "tar"],
            auto_reset=True,
            last_batch_policy=LastBatchPolicy.DROP,
            prepare_first_batch=True,
        )

    def __len__(self):
        return self.num_batches

    def __iter__(self):
        for token in self.iterator:
            inp = token[0]["inp"]
            tar = token[0]["tar"]
            yield inp, tar

# Hierarchy of AMP in Deep Learning Workflows (BF16 / FP16 Mixed Precision)
#
#      +---------------------------------------------------------+
#      |               Deep Neural Networks (Model)              |
#      +---------------------------------------------------------+
#                               |
#      |                 DL Frameworks (e.g., PyTorch)           |
#      |---------------------------------------------------------|
#      |   - Provides AMP support (autocast/GradScaler)          |
#      |   - Exposes APIs to enable mixed precision training     |
#      +---------------------------------------------------------+
#                               |
#      |     Automatic Mixed Precision (AMP) - Hardware Assisted |
#      |---------------------------------------------------------|
#      |   - Integrates with hardware features                   |
#      |   - Controls casting (BF16/FP16 ↔ FP32) on the fly      |
#      |   - Ensures safe ops remain in FP32 automatically       |
#      +---------------------------------------------------------+
#                               |
#      |                Hardware (Tensor Cores, CPUs/GPUs)       |
#      |---------------------------------------------------------|
#      |   - BF16/FP16 Tensor Core acceleration                  |
#      |   - High-throughput, hardware-level support             |
#      +---------------------------------------------------------+
#
# Data travels down through these layers, where AMP orchestrates use of specialized hardware to accelerate
# mixed-precision compute, as visualized in the image above.
#
# In code, AMP typically looks like:
#
#   with autocast(device_type, enabled=True, dtype=torch.bfloat16):
#       y = model(x)    # matmul/conv ops run on Tensor Cores as BF16/FP16, safe ops stay FP32
#       loss = loss_fn(y, target)
#
# Gradient scaling and safe weight management are handled by the framework (see image above).
#
#     Model/DL framework
#           |
#       [autocast]
#           |
#    (BF16/FP16 ops scheduled for tensor cores by AMP)
#           |
#        Hardware execution
#        (Tensor Cores/accelerators)

with torch.no_grad():
    inp, tar = map(lambda x: x.to(device), next(iter(train_data_loader)))
    with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
        gen = model(inp)
    tr_loss = loss_func(gen, tar)
    inp, tar = map(lambda x: x.to(device), next(iter(val_data_loader)))
    with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
        gen = model(inp)
    val_loss = loss_func(gen, tar)
    val_rmse = weighted_rmse(gen, tar)
    if params.distributed:
        torch.distributed.all_reduce(
            tr_loss, op=ReduceOp.AVG, group=comm.get_group("dp")
        )
        torch.distributed.all_reduce(
            val_loss, op=ReduceOp.AVG, group=comm.get_group("dp")
        )
        torch.distributed.all_reduce(
            val_rmse, op=ReduceOp.AVG, group=comm.get_group("dp")
        )
    if world_rank == 0:
        args.tboard_writer.add_scalar("Loss/train", tr_loss.item(), 0)
        args.tboard_writer.add_scalar("Loss/valid", val_loss.item(), 0)
        args.tboard_writer.add_scalar(
            "RMSE(u10m)/valid", val_rmse.cpu().numpy()[0], 0
        )

...

    torch.cuda.nvtx.range_push(f"forward")
    with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
        gen = model(inp)
        loss = loss_func(gen, tar)
    torch.cuda.nvtx.range_pop()  # forward
...

with torch.inference_mode():
    with torch.no_grad():
        for i, data in enumerate(val_data_loader, 0):
            with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
                inp, tar = map(lambda x: x.to(device), data)
                gen = model(inp)
                val_loss += loss_func(gen, tar)
                val_rmse += weighted_rmse(gen, tar)
            valid_steps += 1

        if params.distributed:
            torch.distributed.all_reduce(
                val_loss, op=ReduceOp.AVG, group=comm.get_group("dp")
            )
            torch.distributed.all_reduce(
                val_rmse, op=ReduceOp.AVG, group=comm.get_group("dp")
            )

import sys
import os
import time
import numpy as np
import argparse

import torch
import torch.nn as nn
import torch.optim as optim
from torch.amp import autocast, GradScaler
import torch.multiprocessing
from torch.utils.tensorboard import SummaryWriter
from torch.nn.parallel import DistributedDataParallel

import logging
from utils import logging_utils

logging_utils.config_logger()
from utils.YParams import YParams
from utils import get_data_loader_distributed
from utils.loss import l2_loss, l2_loss_opt
from utils.metrics import weighted_rmse
from utils.plots import generate_images
from networks import vit


def train(params, args, local_rank, world_rank, world_size):
    """
    ==========================================================================
                                   train()
    ==========================================================================
    |  Overall Structure:
    |
    |   +-----------------------------------------------------------+
    |   |        Setup, Data, Model, Optimizer, Scheduler           |
    |   +-----------------------------------------------------------+
    |   |    Initial Logging & Initial Loss/Eval (TensorBoard)      |
    |   +-----------------------------------------------------------+
    |   |    ========== Main Training Loop (epochs) ===========     |
    |   |    |                                               |      |
    |   |    |  1. Per-epoch setup (sampler, timers, mode)   |      |
    |   |    |  2. --------- Per-step (batch) -----------    |      |
    |   |    |  |   a. Data to device, timing/metrics |      |      |
    |   |    |  |   b. Forward, loss, backward, opt   |      |      |
    |   |    |  |   c. Distributed/allreduce          |      |      |
    |   |    |  |   d. Running stats, LR step         |      |      |
    |   |    |  +-------------------------------------+      |      |
    |   |    |  3. Per-epoch eval: validation loader         |      |
    |   |    +-----------------------------------------------+      |
    |   +-----------------------------------------------------------+
    |   |            Final timing and summary stats                 |
    +---------------------------------------------------------------+

    """
    # -------------- (1) Device and CUDNN setup --------------------
    torch.backends.cudnn.benchmark = True
    torch.cuda.set_device(local_rank)
    device = torch.device("cuda:%d" % local_rank)

    # -------------- (2) Data Loaders                               |
    logging.info("rank %d, begin data loader init" % world_rank)
    train_data_loader, train_dataset, train_sampler = get_data_loader_distributed(
        params, params.train_data_path, params.distributed, train=True
    )
    val_data_loader, valid_dataset = get_data_loader_distributed(
        params, params.valid_data_path, params.distributed, train=False
    )
    logging.info("rank %d, data loader initialized" % (world_rank))

    # -------------- (3) Model Instantiation                       |
    model = vit.ViT(params).to(device)

    if params.enable_jit:
        # Optionally use torch.compile for JIT optimization
        model = torch.compile(model)

    # -------------- (4) AMP/Distributed Setup                    |
    if params.amp_dtype == torch.float16:
        scaler = GradScaler("cuda")
    if params.distributed and not args.noddp:
        """
        =========================================================
        DistributedDataParallel (DDP) Overview:

        DDP is PyTorch's mechanism for achieving data-parallel training
        across multiple GPUs, using NCCL for high-performance GPU-to-GPU
        communication. For each GPU/rank, you launch a separate process.
        Backward gradients are automatically all-reduced so each model
        replica stays in sync.

        Example:
            +------------------+
            | Process/Rank 0   |    GPU:0
            | +------------+   |    model parameters θ₀
            | |   Model    |---|-------+
            | +------------+   |       |
            +------------------+       |
                             |         v
            +------------------+     AllReduce: gradients
            | Process/Rank 1   |    across NCCL communicator
            | +------------+   |    (compare to halo exchange
            | |   Model    |---|--------- ring in Jacobi)
            | +------------+   |
            +------------------+

          - Each process has its own CUDA device and model replica
          - Forward/backward compute locally on own batch
          - After backward(), gradients are automatically averaged
            across all GPUs/ranks (using NCCL/AllReduce)
          - Optimizer step updates local model parameters

        Compare this to stencil/halo exchange with MPI/NCCL in
        /distributed-gpu, but DDP allreduces the *whole* gradient,
        not just boundaries.

        Buffer sharing: broadcast_buffers True/False
          - Buffers = non-parameter state (e.g., running stats)
          - True: Syncs these each iteration (default/PyTorch default)
          - False: Leaves them independent on each process

        More: https://pytorch.org/docs/stable/generated/torch.nn.parallel.DistributedDataParallel.html
        =========================================================
        """

        # Optional buffer sharing config for DDP
        if args.disable_broadcast_buffers:
            model = DistributedDataParallel(
                model,
                device_ids=[local_rank],
                bucket_cap_mb=args.bucket_cap_mb,
                broadcast_buffers=False,
                gradient_as_bucket_view=True,
            )
        else:
            model = DistributedDataParallel(
                model, device_ids=[local_rank], bucket_cap_mb=args.bucket_cap_mb
            )

    # -------------- (5) Optimizer                                |
    if params.enable_fused:
        optimizer = optim.Adam(
            model.parameters(), lr=params.lr, fused=True, betas=(0.9, 0.95)
        )
    else:
        optimizer = optim.Adam(model.parameters(), lr=params.lr, betas=(0.9, 0.95))

    # -------------- (6) Log Model                               |
    if world_rank == 0:
        logging.info(model)

    # -------------- (7) Scheduler                               |
    iters = 0
    startEpoch = 0
    if params.lr_schedule == "cosine":
        if params.warmup > 0:
            lr_scale = lambda x: min(
                (x + 1) / params.warmup,
                0.5 * (1 + np.cos(np.pi * x / params.num_iters)),
            )
            scheduler = torch.optim.lr_scheduler.LambdaLR(optimizer, lr_scale)
        else:
            scheduler = torch.optim.lr_scheduler.CosineAnnealingLR(
                optimizer, T_max=params.num_iters
            )
    else:
        scheduler = None

    # -------------- (8) Loss Selection                          |
    if params.enable_jit:
        loss_func = l2_loss_opt
    else:
        loss_func = l2_loss

    # -------------- (9) Initial Logging to TensorBoard          |
    if world_rank == 0:
        logging.info("Starting Training Loop...")

    # ==[ Initial Loss/Validation Logging ]==========================
    with torch.no_grad():
        inp, tar = map(lambda x: x.to(device), next(iter(train_data_loader)))
        gen = model(inp)
        tr_loss = loss_func(gen, tar)
        inp, tar = map(lambda x: x.to(device), next(iter(val_data_loader)))
        gen = model(inp)
        val_loss = loss_func(gen, tar)
        val_rmse = weighted_rmse(gen, tar)
        if params.distributed:
            torch.distributed.all_reduce(tr_loss)
            torch.distributed.all_reduce(val_loss)
            torch.distributed.all_reduce(val_rmse)
        if world_rank == 0:
            args.tboard_writer.add_scalar("Loss/train", tr_loss.item() / world_size, 0)
            args.tboard_writer.add_scalar("Loss/valid", val_loss.item() / world_size, 0)
            args.tboard_writer.add_scalar(
                "RMSE(u10m)/valid", val_rmse.cpu().numpy()[0] / world_size, 0
            )

    # ========== MAIN TRAINING LOOP (epochs) ==========
    params.num_epochs = params.num_iters // len(train_data_loader)
    iters = 0
    t1 = time.time()
    for epoch in range(startEpoch, startEpoch + params.num_epochs):
        # ---[A] Epoch: prep, sampler, timers ---
        torch.cuda.synchronize()  # Ensure correct epoch timing (sync GPU)
        if params.distributed and (train_sampler is not None):
            train_sampler.set_epoch(epoch)
        start = time.time()
        tr_loss = []
        tr_time = 0.0
        dat_time = 0.0
        log_time = 0.0

        model.train()
        step_count = 0

        # ----------- B. PER-BATCH TRAINING ------------
        for i, data in enumerate(train_data_loader, 0):
            # (Optional) Profiling: Begin/End CUDA profiler at a certain epoch
            if world_rank == 0:
                if epoch == 3 and i == 0:
                    torch.cuda.profiler.start()
                if epoch == 3 and i == len(train_data_loader) - 1:
                    torch.cuda.profiler.stop()

            torch.cuda.nvtx.range_push(f"step {i}")
            iters += 1
            dat_start = time.time()
            torch.cuda.nvtx.range_push(f"data copy in {i}")

            # --- Copy batch to GPU ---
            inp, tar = map(lambda x: x.to(device), data)
            torch.cuda.nvtx.range_pop()  # data copy in

            tr_start = time.time()
            b_size = inp.size(0)

            # --- ZERO GRAD ---
            optimizer.zero_grad()

            # --- Forward w/ autocast (AMP) ---
            torch.cuda.nvtx.range_push(f"forward")
            with autocast("cuda", enabled=params.amp_enabled, dtype=params.amp_dtype):
                gen = model(inp)
                loss = loss_func(gen, tar)
            torch.cuda.nvtx.range_pop()  # forward

            # --- Backward, Step (AMP or standard) ---
            if params.amp_dtype == torch.float16:
                scaler.scale(loss).backward()
                torch.cuda.nvtx.range_push(f"optimizer")
                scaler.step(optimizer)
                torch.cuda.nvtx.range_pop()  # optimizer
                scaler.update()
            else:
                loss.backward()
                torch.cuda.nvtx.range_push(f"optimizer")
                optimizer.step()
                torch.cuda.nvtx.range_pop()  # optimizer

            # --- Allreduce if distributed ---
            if params.distributed:
                torch.distributed.all_reduce(loss)
            tr_loss.append(loss.item() / world_size)

            torch.cuda.nvtx.range_pop()  # step
            # --- LR Scheduler Step ---
            scheduler.step()

            # --- Time/Stats ---
            tr_end = time.time()
            tr_time += tr_end - tr_start
            dat_time += tr_start - dat_start
            step_count += 1

        # =====[ End of Training steps for this epoch ]=====
        torch.cuda.synchronize()  # Accurate epoch timing
        end = time.time()

        # ----------- C. Epoch-End Reporting/Logging (Rank 0) -------
        if world_rank == 0:
            iters_per_sec = step_count / (end - start)
            samples_per_sec = params["global_batch_size"] * iters_per_sec
            logging.info(
                "Time taken for epoch %i is %f sec, avg %f samples/sec",
                epoch + 1,
                end - start,
                samples_per_sec,
            )
            logging.info("  Avg train loss=%f" % np.mean(tr_loss))
            args.tboard_writer.add_scalar("Loss/train", np.mean(tr_loss), iters)
            args.tboard_writer.add_scalar(
                "Learning Rate", optimizer.param_groups[0]["lr"], iters
            )
            args.tboard_writer.add_scalar("Avg iters per sec", iters_per_sec, iters)
            args.tboard_writer.add_scalar("Avg samples per sec", samples_per_sec, iters)
            fig = generate_images([inp, tar, gen])
            args.tboard_writer.add_figure("Visualization, t2m", fig, iters, close=True)

        # ========== D. Validation Evaluation ============
        val_start = time.time()
        val_loss = torch.zeros(1, device=device)
        val_rmse = torch.zeros(
            (params.n_out_channels), dtype=torch.float32, device=device
        )
        valid_steps = 0
        model.eval()

        with torch.inference_mode():
            with torch.no_grad():
                for i, data in enumerate(val_data_loader, 0):
                    with autocast(
                        "cuda", enabled=params.amp_enabled, dtype=params.amp_dtype
                    ):
                        inp, tar = map(lambda x: x.to(device), data)
                        gen = model(inp)
                        val_loss += loss_func(gen, tar)
                        val_rmse += weighted_rmse(gen, tar)
                    valid_steps += 1

                if params.distributed:
                    torch.distributed.all_reduce(val_loss)
                    val_loss /= world_size
                    torch.distributed.all_reduce(val_rmse)
                    val_rmse /= world_size

        val_rmse /= valid_steps  # Avg validation rmse
        val_loss /= valid_steps
        val_end = time.time()

        # ---------- (E) Validation logging (TensorBoard/Console) ----------
        if world_rank == 0:
            logging.info("  Avg val loss={}".format(val_loss.item()))
            logging.info("  Total validation time: {} sec".format(val_end - val_start))
            args.tboard_writer.add_scalar("Loss/valid", val_loss, iters)
            args.tboard_writer.add_scalar(
                "RMSE(u10m)/valid", val_rmse.cpu().numpy()[0], iters
            )
            args.tboard_writer.flush()

    # ===== Final Timing Summary =====
    t2 = time.time()
    tottime = t2 - t1

    # ==========================================================================
    #    End of train()
    # ==========================================================================


if __name__ == "__main__":
    parser = argparse.ArgumentParser()
    parser.add_argument(
        "--run_num",
        default="00",
        type=str,
        help="tag for indexing the current experiment",
    )
    parser.add_argument(
        "--yaml_config",
        default="./config/ViT.yaml",
        type=str,
        help="path to yaml file containing training configs",
    )
    parser.add_argument(
        "--config", default="base", type=str, help="name of desired config in yaml file"
    )
    parser.add_argument(
        "--amp_mode",
        default="none",
        type=str,
        choices=["none", "fp16", "bf16"],
        help="select automatic mixed precision mode",
    )
    parser.add_argument(
        "--enable_fused", action="store_true", help="enable fused Adam optimizer"
    )
    parser.add_argument(
        "--enable_jit", action="store_true", help="enable JIT compilation"
    )
    parser.add_argument(
        "--local_batch_size",
        default=None,
        type=int,
        help="local batchsize (manually override global_batch_size config setting)",
    )
    parser.add_argument(
        "--num_iters", default=None, type=int, help="number of iters to run"
    )
    parser.add_argument(
        "--num_data_workers",
        default=None,
        type=int,
        help="number of data workers for data loader",
    )
    parser.add_argument(
        "--data_loader_config",
        default=None,
        type=str,
        choices=["pytorch", "dali"],
        help="dataloader configuration. choices: 'pytorch', 'dali'",
    )
    parser.add_argument(
        "--bucket_cap_mb", default=25, type=int, help="max message bucket size in mb"
    )
    parser.add_argument(
        "--disable_broadcast_buffers",
        action="store_true",
        help="disable syncing broadcasting buffers",
    )
    parser.add_argument(
        "--noddp", action="store_true", help="disable DDP communication"
    )
    args = parser.parse_args()

    run_num = args.run_num

    params = YParams(os.path.abspath(args.yaml_config), args.config)

    # Update config with modified args
    # set up amp
    if args.amp_mode != "none":
        params.update({"amp_mode": args.amp_mode})
    amp_dtype = torch.float32

    if params.amp_mode == "fp16":
        amp_dtype = torch.float16
    elif params.amp_mode == "bf16":
        amp_dtype = torch.bfloat16

    params.update(
        {"amp_enabled": amp_dtype is not torch.float32, "amp_dtype": amp_dtype}
    )

    if args.enable_fused:
        params.update({"enable_fused": args.enable_fused})

    if args.enable_jit:
        params.update({"enable_jit": args.enable_jit})

    if args.data_loader_config:
        params.update({"data_loader_config": args.data_loader_config})

    if args.num_iters:
        params.update({"num_iters": args.num_iters})

    if args.num_data_workers:
        params.update({"num_data_workers": args.num_data_workers})

    params.distributed = False
    if "WORLD_SIZE" in os.environ:
        params.distributed = int(os.environ["WORLD_SIZE"]) > 1
        world_size = int(os.environ["WORLD_SIZE"])
    else:
        world_size = 1

    world_rank = 0
    local_rank = 0
    if params.distributed:
        torch.distributed.init_process_group(backend="nccl", init_method="env://")
        world_rank = torch.distributed.get_rank()
        local_rank = int(os.environ["LOCAL_RANK"])

    if args.local_batch_size:
        # Manually override batch size
        params.local_batch_size = args.local_batch_size
        params.update({"global_batch_size": world_size * args.local_batch_size})
    else:
        # Compute local batch size based on number of ranks
        params.local_batch_size = params.global_batch_size // world_size

    # for dali data loader, set the actual number of data shards and id
    params.data_num_shards = world_size
    params.data_shard_id = world_rank

    # Set up directory
    baseDir = params.expdir
    expDir = os.path.join(
        baseDir, args.config + "/%dGPU/" % (world_size) + str(run_num) + "/"
    )
    if world_rank == 0:
        if not os.path.isdir(expDir):
            os.makedirs(expDir)
        logging_utils.log_to_file(
            logger_name=None, log_filename=os.path.join(expDir, "out.log")
        )
        params.log()
        args.tboard_writer = SummaryWriter(log_dir=os.path.join(expDir, "logs/"))

    params.experiment_dir = os.path.abspath(expDir)

    train(params, args, local_rank, world_rank, world_size)

    if params.distributed:
        torch.distributed.barrier()
    logging.info("DONE ---- rank %d" % world_rank)

import sys
import os
import time
import numpy as np
import argparse
import pynvml

import torch
import torch.nn as nn
import torch.optim as optim
from torch.amp import autocast, GradScaler
import torch.multiprocessing
from torch.utils.tensorboard import SummaryWriter
from torch.nn.parallel import DistributedDataParallel
from torch.distributed import ReduceOp

import logging
from utils import logging_utils
import warnings
warnings.simplefilter("ignore", FutureWarning)

logging_utils.config_logger()
from utils.YParams import YParams
from utils import get_data_loader_distributed
from utils import comm
from utils.loss import l2_loss, l2_loss_opt
from utils.metrics import weighted_rmse
from networks import vit
from networks import vit_te

from distributed.mappings import init_ddp_model_and_reduction_hooks
from distributed.helpers import init_params_for_shared_weights

from utils.plots import generate_images


def train(params, args, local_rank, world_rank, world_size):
    # ----------------------------------------------------------------------- #
    # (1) Device & Library Setup
    # ----------------------------------------------------------------------- #
    # Ensure deterministic performance for convolution operations and set device
    torch.backends.cudnn.benchmark = True
    torch.cuda.set_device(local_rank)
    device = torch.device(f"cuda:{local_rank}")

    # Initialize GPU monitoring to track memory usage
    pynvml.nvmlInit()
    nvml_handle = pynvml.nvmlDeviceGetHandleByIndex(device.index)

    # ----------------------------------------------------------------------- #
    # (2) DataLoader Initialization
    # ----------------------------------------------------------------------- #
    # Get distributed train/validation data loaders and samplers
    logging.info("rank %d, begin data loader init" % world_rank)
    train_data_loader, train_dataset, train_sampler = get_data_loader_distributed(
        params, params.train_data_path, params.distributed, train=True
    )
    val_data_loader, valid_dataset = get_data_loader_distributed(
        params, params.valid_data_path, params.distributed, train=False
    )
    logging.info("rank %d, data loader initialized" % world_rank)

    # ----------------------------------------------------------------------- #
    # (3) Model Initialization & JIT Compilation
    # ----------------------------------------------------------------------- #
    # Choose Transformer Engine or native ViT backend
    if params.model_backend == 'transformer-engine':
        logging.info("using transformer-engine backend")
        model = vit_te.ViT(params).to(device)
    else:
        logging.info("using native backend")
        model = vit.ViT(params).to(device)

    # JIT compilation (optional, for acceleration)
    if params.enable_jit:
        # NOTE: DDP interoperability with torch.compile may need special handling
        model = torch.compile(model)

    # AMP: Automatic Mixed Precision
    if params.amp_dtype == torch.float16:
        scaler = GradScaler('cuda')

    # ----------------------------------------------------------------------- #
    # (4) Distributed/TP Shared Weight Synchronization
    # ----------------------------------------------------------------------- #
    # If tensor/pipeline parallel model requires, sync weights

    """
    MODEL PARALLELISM: TENSOR & PIPELINE (PyTorch/pynvml, Exascale Style)
    -----------------------------------------------------------------------

    [How deep learning tensor/pipeline parallelism actually works in PyTorch,
     and how parameter/init synchronization mimics exascale Jacobi/MPI code.
     Device/memory setup and monitoring via torch.cuda & pynvml -- see below.]

    =====================================================================
    (1) TENSOR PARALLELISM (PyTorch distributed, weight sharding, sync)
    =====================================================================

    Model parameter broadcast/init (like MPI_Bcast in Jacobi, see @2025-11-16):

              +------------------- torch.distributed.broadcast (NCCL/MPI)--------------------+
              |                                                                              |
        +----------+     +----------+     +----------+     +----------+                  +---v------+
        |  GPU 0   |     |  GPU 1   |     |  GPU 2   |     |  GPU 3   |                  | Python   |
        | (rank 0) |     | (rank 1) |     | (rank 2) |     | (rank 3) |                  | process  |
        +----+-----+     +-----+----+     +-----+----+     +-----+----+                  +---+------+
             |                 |                |                |                            |
             |                 |                |                |                            |
             |      (shard large weights via param.split())      |                            |
             +-----------------|---------------------------------+----------------------------+
                               | (each GPU stores a partition)
                               +-------------------------+
                                         |    (forward/backward: partial matmuls, reduce/add)
    (compare: Jacobi halo rows exchanged with MPI_Sendrecv() and parameters broadcast with MPI_Bcast)

    =====================================================================
    (2) PIPELINE PARALLELISM (PyTorch: staged blocks, microbatch pipeline)
    =====================================================================

        Input Batch
            |
        +----------+    +----------+    +----------+    +----------+
        |  GPU 0   |--->|  GPU 1   |--->|  GPU 2   |--->|  GPU 3   |
        | (Stage 0)|    | (Stage 1)|    | (Stage 2)|    | (Stage 3)|
        +----------+    +----------+    +----------+    +----------+
             |              |                |                |
        [Encoder 0]    [Encoder 1]     [Encoder 2]      [Encoder 3]
             |              |                |                |
          (microbatch split, data passed stage to stage)
             |
         torch.distributed.broadcast(init params) --- like Jacobi: all subdomains/ranks
                                                        must agree on boundaries at setup

    =====================================================================
    (3) DEVICE & MEMORY MANAGEMENT (PyTorch, pynvml, MPI Analogy)
    =====================================================================

        +-----------------------------------------------------------+
        |                   Python Process (per rank)               |
        +-----------------------------------------------------------+
        | torch.cuda.set_device(local_rank)                         |
        | device = torch.device(f"cuda:{local_rank}")               |
        | model.to(device)                                          |
        | pynvml.nvmlInit()                     (get handle for GPU)|
        | nvmlDeviceGetMemoryInfo(nvml_handle)     (GB used)        |
        +-----------------------------------------------------------+
                          |
    [like Jacobi/MPI: cudaSetDevice, deviceCount, rank <-> device mapping]

    =====================================================================
    (4) SYNC & COLLECTIVES: PyTorch vs Jacobi MPI
    =====================================================================

        +---------------------------+     +------------------------------+
        |      PyTorch World        |     |    Exascale Jacobi (C/MPI)   |
        +---------------------------+     +------------------------------+
        | torch.distributed.broadcast| <->| MPI_Bcast (e.g. ncclUniqueId)|
        | torch.distributed.all_reduce|<->| MPI_Allreduce (convergence)  |
        | torch.distributed.barrier  | <->| MPI_Barrier                  |
        +---------------------------+     +------------------------------+

    KEY FLOW:
      - PyTorch uses torch.distributed backends (NCCL/MPI) to implement
        the same process-group collectives as Jacobi C/MPI: sync weights,
        share state, coordinate progress.
      - init_params_for_shared_weights(model) triggers these bcasts.
      - pynvml, torch.cuda lifecycles mirror cuda runtime and info calls
        in Jacobi code (“assign rank to device”, “log mem stats”).

    =====================================================================
    (5) KEY MAPPING
    =====================================================================

        PyTorch init_params_for_shared_weights(model):
            |
            +---> torch.distributed.broadcast(...) for all shared (sharded) params,
                 often per process-group (tp, cp)
        MPI Jacobi:
            |
            +---> MPI_Bcast()/Sendrecv() for domain boundaries, ids

    See /distributed-gpu for the equivalent device set,
    rank assignment, MPI_Bcast/ncclUniqueId & ncclCommInitRank, mirrored here in torch:
        - torch.cuda.device         <-> cudaSetDevice(rank % num_devices)
        - torch.distributed actions <-> MPI_SENDRECV/ALLREDUCE/BCAST
        - pynvml.nvmlDeviceGet...   <-> cudaMemGetInfo/MPI logging

    """

    if comm.get_size("tp-cp") > 1:
        init_params_for_shared_weights(model)

    # Wrap model with DDP if required
    if params.distributed and not args.noddp:
        model = init_ddp_model_and_reduction_hooks(
            model,
            device_ids=[local_rank],
            output_device=[local_rank],
            bucket_cap_mb=args.bucket_cap_mb
        )

    # ----------------------------------------------------------------------- #
    # (5) Optimizer Setup
    # ----------------------------------------------------------------------- #
    # Use fused Adam optimizer if enabled
    if params.enable_fused:
        optimizer = optim.Adam(
            model.parameters(), lr=params.lr, fused=True, betas=(0.9, 0.95)
        )
    else:
        optimizer = optim.Adam(model.parameters(), lr=params.lr, betas=(0.9, 0.95))

    # ----------------------------------------------------------------------- #
    # (6) Model Logging & Memory Monitoring (rank 0 master only)
    # ----------------------------------------------------------------------- #
    if world_rank == 0:
        logging.info(model)
        all_mem_gb = pynvml.nvmlDeviceGetMemoryInfo(nvml_handle).used / (1024.0**3)
        logging.info(f"Scaffolding memory high watermark: {all_mem_gb} GB.")

    iters = 0
    startEpoch = 0

    # ----------------------------------------------------------------------- #
    # (7) Learning Rate Scheduler Configuration
    # ----------------------------------------------------------------------- #
    if params.lr_schedule == "cosine":
        if params.warmup > 0:
            # Linear warmup to cosine decay
            lr_scale = lambda x: min(
                (x + 1) / params.warmup,
                0.5 * (1 + np.cos(np.pi * x / params.num_iters)),
            )
            scheduler = torch.optim.lr_scheduler.LambdaLR(optimizer, lr_scale)
        else:
            scheduler = torch.optim.lr_scheduler.CosineAnnealingLR(
                optimizer, T_max=params.num_iters
            )
    else:
        scheduler = None

    # ----------------------------------------------------------------------- #
    # (8) Loss Function Selection
    # ----------------------------------------------------------------------- #
    # Use JIT-optimized or plain loss depending on setting
    if params.enable_jit:
        loss_func = l2_loss_opt
    else:
        loss_func = l2_loss

    # ----------------------------------------------------------------------- #
    # (9) Initial Logging and Baseline Metrics
    # ----------------------------------------------------------------------- #
    if world_rank == 0:
        logging.info("Starting Training Loop...")

    # Compute & log initial train/val loss and RMSE before epochs begin
    with torch.no_grad():
        # Take first batch from training and validation for baseline
        inp, tar = map(lambda x: x.to(device), next(iter(train_data_loader)))
        with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
            gen = model(inp)
        tr_loss = loss_func(gen, tar)
        inp, tar = map(lambda x: x.to(device), next(iter(val_data_loader)))
        with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
            gen = model(inp)
        val_loss = loss_func(gen, tar)
        val_rmse = weighted_rmse(gen, tar)
        # Reduce baseline metrics across data-parallel group if needed
        if params.distributed:
            torch.distributed.all_reduce(
                tr_loss, op=ReduceOp.AVG, group=comm.get_group("dp")
            )
            torch.distributed.all_reduce(
                val_loss, op=ReduceOp.AVG, group=comm.get_group("dp")
            )
            torch.distributed.all_reduce(
                val_rmse, op=ReduceOp.AVG, group=comm.get_group("dp")
            )
        if world_rank == 0:
            args.tboard_writer.add_scalar("Loss/train", tr_loss.item(), 0)
            args.tboard_writer.add_scalar("Loss/valid", val_loss.item(), 0)
            args.tboard_writer.add_scalar(
                "RMSE(u10m)/valid", val_rmse.cpu().numpy()[0], 0
            )

    # ----------------------------------------------------------------------- #
    # (10) Main Training/Validation Loop
    # ----------------------------------------------------------------------- #
    params.num_epochs = params.num_iters // len(train_data_loader)
    iters = 0
    t1 = time.time()
    for epoch in range(startEpoch, startEpoch + params.num_epochs):
        torch.cuda.synchronize()  # ensure accurate epoch timings
        # For reproducibility in distributed scenario, reset epoch for sampler
        if params.distributed and (train_sampler is not None):
            train_sampler.set_epoch(epoch)
        start = time.time()
        tr_loss = []
        tr_time = 0.0
        dat_time = 0.0
        log_time = 0.0

        model.train()
        step_count = 0

        # (10.1) Training steps per batch
        for i, data in enumerate(train_data_loader, 0):
            # (a) Optionally enable profiling for diagnostics on rank 0
            if world_rank == 0:
                if epoch == 3 and i == 0:
                    torch.cuda.profiler.start()
                if epoch == 3 and i == len(train_data_loader) - 1:
                    torch.cuda.profiler.stop()

            torch.cuda.nvtx.range_push(f"step {i}")
            iters += 1
            dat_start = time.time()
            torch.cuda.nvtx.range_push(f"data copy in {i}")

            # (b) Copy data to device/GPU
            inp, tar = map(lambda x: x.to(device), data)
            torch.cuda.nvtx.range_pop()  # end data copy timing

            tr_start = time.time()
            b_size = inp.size(0)
            optimizer.zero_grad()

            torch.cuda.nvtx.range_push("forward")
            # (c) Forward pass and loss under autocast for AMP
            with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
                gen = model(inp)
                loss = loss_func(gen, tar)
            torch.cuda.nvtx.range_pop()  # end forward timing

            # Optionally log memory usage after first forward pass
            if world_rank == 0 and i == 1:
                all_mem_gb = pynvml.nvmlDeviceGetMemoryInfo(nvml_handle).used / (1024.0**3)
                logging.info(f" Memory usage after forward pass: {all_mem_gb} GB.")

            # (d) Backward & optimizer step (support autocast/scaler if fp16 AMP)
            if params.amp_dtype == torch.float16:
                scaler.scale(loss).backward()
                torch.cuda.nvtx.range_push("optimizer")
                scaler.step(optimizer)
                torch.cuda.nvtx.range_pop()  # optimizer
                scaler.update()
            else:
                loss.backward()
                torch.cuda.nvtx.range_push("optimizer")
                optimizer.step()
                torch.cuda.nvtx.range_pop()  # optimizer

            # (e) Synchronize loss across data-parallel processes if distributed
            if params.distributed:
                torch.distributed.all_reduce(
                    loss, op=ReduceOp.AVG, group=comm.get_group("dp")
                )
            tr_loss.append(loss.item())

            torch.cuda.nvtx.range_pop()  # end step

            # (f) Learning rate schedule step
            scheduler.step()

            # (g) Timing and diagnostics
            tr_end = time.time()
            tr_time += tr_end - tr_start
            dat_time += tr_start - dat_start
            step_count += 1

        torch.cuda.synchronize()  # epoch synchronization for timing
        end = time.time()

        # (10.2) Logging and visualization (rank 0 only)
        if world_rank == 0:
            iters_per_sec = step_count / (end - start)
            samples_per_sec = params["global_batch_size"] * iters_per_sec
            logging.info(
                "Time taken for epoch %i is %f sec, avg %f samples/sec",
                epoch + 1,
                end - start,
                samples_per_sec,
            )
            logging.info("  Avg train loss=%f" % np.mean(tr_loss))
            args.tboard_writer.add_scalar("Loss/train", np.mean(tr_loss), iters)
            args.tboard_writer.add_scalar(
                "Learning Rate", optimizer.param_groups[0]["lr"], iters
            )
            args.tboard_writer.add_scalar("Avg iters per sec", iters_per_sec, iters)
            args.tboard_writer.add_scalar("Avg samples per sec", samples_per_sec, iters)
            # Visualize a sample result
            fig = generate_images([inp, tar, gen])
            args.tboard_writer.add_figure("Visualization, t2m", fig, iters, close=True)

        # ------------------------------------------------------------------- #
        # (10.3) Validation Evaluation Phase
        # ------------------------------------------------------------------- #
        val_start = time.time()
        val_loss = torch.zeros(1, device=device)
        val_rmse = torch.zeros(
            (params.n_out_channels), dtype=torch.float32, device=device
        )
        valid_steps = 0
        model.eval()

        with torch.inference_mode():
            with torch.no_grad():
                for i, data in enumerate(val_data_loader, 0):
                    with autocast('cuda', enabled=params.amp_enabled, dtype=params.amp_dtype):
                        inp, tar = map(lambda x: x.to(device), data)
                        gen = model(inp)
                        val_loss += loss_func(gen, tar)
                        val_rmse += weighted_rmse(gen, tar)
                    valid_steps += 1

                # Reduce validation metrics across all ranks for distributed
                if params.distributed:
                    torch.distributed.all_reduce(
                        val_loss, op=ReduceOp.AVG, group=comm.get_group("dp")
                    )
                    torch.distributed.all_reduce(
                        val_rmse, op=ReduceOp.AVG, group=comm.get_group("dp")
                    )

        # Normalize validation metrics by number of steps
        val_rmse /= valid_steps
        val_loss /= valid_steps
        val_end = time.time()

        # (10.4) Log validation results (only rank 0 logs and writes)
        if world_rank == 0:
            logging.info("  Avg val loss={}".format(val_loss.item()))
            logging.info("  Total validation time: {} sec".format(val_end - val_start))
            args.tboard_writer.add_scalar("Loss/valid", val_loss, iters)
            args.tboard_writer.add_scalar(
                "RMSE(u10m)/valid", val_rmse.cpu().numpy()[0], iters
            )
            args.tboard_writer.flush()

    # ----------------------------------------------------------------------- #
    # (11) Cleanup and Final Timing
    # ----------------------------------------------------------------------- #
    torch.cuda.synchronize()
    t2 = time.time()
    tottime = t2 - t1
    pynvml.nvmlShutdown()

if __name__ == "__main__":
    parser = argparse.ArgumentParser()
    parser.add_argument(
        "--run_num",
        default="00",
        type=str,
        help="tag for indexing the current experiment",
    )
    parser.add_argument(
        "--yaml_config",
        default="./config/ViT.yaml",
        type=str,
        help="path to yaml file containing training configs",
    )
    parser.add_argument(
        "--config", default="base", type=str, help="name of desired config in yaml file"
    )
    parser.add_argument(
        "--amp_mode",
        default="none",
        type=str,
        choices=["none", "fp16", "bf16"],
        help="select automatic mixed precision mode",
    )
    parser.add_argument(
        "--enable_fused", action="store_true", help="enable fused Adam optimizer"
    )
    parser.add_argument(
        "--enable_jit", action="store_true", help="enable JIT compilation"
    )
    parser.add_argument(
        "--local_batch_size",
        default=None,
        type=int,
        help="local batchsize (manually override global_batch_size config setting)",
    )
    parser.add_argument(
        "--num_iters", default=None, type=int, help="number of iters to run"
    )
    parser.add_argument(
        "--num_data_workers",
        default=None,
        type=int,
        help="number of data workers for data loader",
    )
    parser.add_argument(
        "--data_loader_config",
        default=None,
        type=str,
        choices=["pytorch", "dali"],
        help="dataloader configuration. choices: 'pytorch', 'dali'",
    )
    parser.add_argument(
        "--bucket_cap_mb", default=25, type=int, help="max message bucket size in mb"
    )
    parser.add_argument(
        "--disable_broadcast_buffers",
        action="store_true",
        help="disable syncing broadcasting buffers",
    )
    parser.add_argument(
        "--noddp", action="store_true", help="disable DDP communication"
    )

    # model parallelism arguments
    parser.add_argument(
        "--tensor_parallel",
        default=1,
        type=int,
        help="Number of GPUs for tensor parallelism",
    )
    parser.add_argument(
        "--context_parallel",
        default=1,
        type=int,
        help="Number of GPUs for context parallelism",
    )
    parser.add_argument(
        "--parallel_order",
        default="tp-cp-dp",
        type=str,
        help="Order of ranks for parallelism",
    )

    args = parser.parse_args()

    run_num = args.run_num

    params = YParams(os.path.abspath(args.yaml_config), args.config)

    # Update config with modified args
    # set up amp
    if args.amp_mode != "none":
        params.update({"amp_mode": args.amp_mode})
    amp_dtype = torch.float32
    if params.amp_mode == "fp16":
        amp_dtype = torch.float16
    elif params.amp_mode == "bf16":
        amp_dtype = torch.bfloat16

    params.update(
        {"amp_enabled": amp_dtype is not torch.float32, "amp_dtype": amp_dtype}
    )

    if args.enable_fused:
        params.update({"enable_fused": args.enable_fused})

    if args.enable_jit:
        params.update({"enable_jit": args.enable_jit})

    if args.data_loader_config:
        params.update({"data_loader_config": args.data_loader_config})

    if args.num_iters:
        params.update({"num_iters": args.num_iters})

    if args.num_data_workers:
        params.update({"num_data_workers": args.num_data_workers})

    params.distributed = False

    # setup model parallel sizes
    params["tp"] = args.tensor_parallel
    params["cp"] = args.context_parallel
    params["order"] = args.parallel_order
    # initialize comm
    comm.init(params, verbose=True)

    # get info from comm
    world_size = comm.get_world_size()
    world_rank = comm.get_world_rank()
    local_rank = comm.get_local_rank()
    params.distributed = world_size > 1

    assert (
        params["global_batch_size"] % comm.get_size("dp") == 0
    ), f"Error, cannot evenly distribute {params['global_batch_size']} across {comm.get_size('dp')} GPU."

    if args.local_batch_size:
        # Manually override batch size
        params.local_batch_size = args.local_batch_size
        params.update(
            {"global_batch_size": comm.get_size("dp") * args.local_batch_size}
        )
    else:
        # Compute local batch size based on number of ranks
        params.local_batch_size = int(
            params["global_batch_size"] // comm.get_size("dp")
        )

    # for data loader, set the actual number of data shards and id
    params.data_num_shards = comm.get_size("dp")
    params.data_shard_id = comm.get_rank("dp")

    # Set up directory
    baseDir = params.expdir
    expDir = os.path.join(
        baseDir, args.config + "/%dMP/" % (comm.get_size("tp-cp")) + str(run_num) + "/"
    )
    if world_rank == 0:
        if not os.path.isdir(expDir):
            os.makedirs(expDir)
        logging_utils.log_to_file(
            logger_name=None, log_filename=os.path.join(expDir, "out.log")
        )
        params.log()
        args.tboard_writer = SummaryWriter(log_dir=os.path.join(expDir, "logs/"))

    params.experiment_dir = os.path.abspath(expDir)

    train(params, args, local_rank, world_rank, world_size)

    if params.distributed:
        torch.distributed.barrier()
    logging.info("DONE ---- rank %d" % world_rank)
